Rahmen: FORM™ Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-9™ Adjustable Geometry. 2 Position Axle. 160mm Travel. FORM™ Alloy Rear Triangle
Federgabel: Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
Federung (V): 170mm
Dämpfer: Fox Float X Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ
Federung (H): 160mm
Steuersatz: FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Vorbau: Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m
Lenker: Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Griffe: ODI Elite Pro Lock On
Bremsen: Shimano SLX Trail 4 Piston | Metal Pads | Front: Shimano RT64 203mm | Rear: Shimano RT64 180mm
Schalthebel: Shimano SLX
Schaltwerk: Shimano XT
Kurbel: Race Face Aeffect Cinch | 32T | 24mm Spindle | 170mm Crank Length
Tretlager: FSA BB92 24mm
Cassette: Shimano Deore 10-51T 12spd
Kette: Shimano M6100
Vorderradnabe: Rocky Mountain Sealed Boost 15mm
Hinterradnabe: Shimano XT Boost 148mm
Speichen: DT Swiss Competition 2.0/1.8/2.0
Felge: WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape | Valves Incl
Reifen: Front: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | Rear: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready |
Sattelstütze: Race Face Aeffect R Dropper 30.9mm | Shimano MT500 Remote | SM = 125mm | MD = 150mm | LG - XL = 175mm
Sattel: WTB Volt Race 142
